CDM-625 Advanced Satellite Modem
Appendix F
Once all events are compiled, the Stored-Events screen appears as shown here:
Stored Events:
#084 Info
On the top line – Use the
To clear the Stored -Events Log, use the
arrow keys to select Yes. Press ENTER when done.
▲▼
On the bottom line – To view the Stored-Events Log: With the cursor on the entry number, use
the arrow keys to scroll through the entries. Up to 512 entries are stored.
▲▼
Each entry provides the following information:
Item
Entry Type
Entry Number
Date
Time
Description of the
fault/information
F.3.3.3.3.4.3.1.4 ODU: FSK-control  BUC  Advanced-FSK  LPOD
Statistics:
Config
Use the arrow keys to select Config or Stored-Statistics, and then press ENTER.
▲▼
ODU: FSK-control  BUC  Advanced-FSK  LPOD (2LPODs
Online/Offline LPOD) Statistics Config
Stats: Logging=Enabled
Averaging=Disabled
Use the arrow keys to select Logging, Interval, Averaging, or Clear-All, and then use the
▲▼
arrow keys to set that setting:
▲▼
Clear-All: No
- PWR ON
◄ ► arrow keys to select between log entries and the Clear-All option.
Comments
• Info (Information)
• Fault
• Clear (fault cleared)
001 through 511
European Day-Month-Year (DD-MM-YY) format
Hour:Minute:Second (HH:MM:SS) format
Example: Info – PWR ON
(2LPODs Online/Offline LPOD) Statistics
Stored-Statistics
(No,Yes)
10/12/10 12:52:08
arrow keys to select Clear-All, and then use the
▲▼
Interval=10 min
Clear-All=No (◄ ►)
F–31
Revision 13
MN-CDM625
()
