CDM-625 Advanced Satellite Modem
Introduction
Option
G.703 Clock Extension
IP Packet Card
Processor
Payload
Compression
Header
Compression
Advanced QoS
AES Encryption
Advanced Network Timing (ANT)
BUC Power Supplies
Main Power Supplies
Description and Comments
G.703 Clock Extension
IP Packet Processor daughter card
Data rate up to 5 Mbps or Symbol rate up to 1200 ksps (ACM)
Data rate up to 10 Mbps or Symbol rate up to 4100 ksps (ACM)
Data rate up to 15 Mbps or Symbol rate up to 4100 ksps (ACM)
Data rate up to 20 Mbps or Symbol rate up to 4100 ksps (ACM)
Data rate up to 25 Mbps or Symbol rate up to 4100 ksps (ACM)
Data rate up to 5 Mbps or Symbol rate up to 1200 ksps (ACM)
Data rate up to 10 Mbps or Symbol rate up to 4100 ksps (ACM)
Data rate up to 15 Mbps or Symbol rate up to 4100 ksps (ACM)
Data rate up to 20 Mbps or Symbol rate up to 4100 ksps (ACM)
Data rate up to 25 Mbps or Symbol rate up to 4100 ksps (ACM)
Advanced QoS
Tx Packet Encryption / Rx Packet Decryption
IEEE-1588v2 Precision Timing Protocol (PTP)
24V, 100W
48V, 150W @ 50° C (180W@ 35° C)
100-240 VAC Nominal
90-264 VAC Maximum
43-60 VDC Nominal
36-60 VDC Maximum
1–9
Revision 13
MN-CDM625
Installation Method
FAST
HARDWARE
FAST
FAST
FAST
FAST
FAST
FAST
FAST
FAST
FAST
FAST
FAST
FAST
REV 2 HARDWARE /
FAST
HARDWARE
HARDWARE
HARDWARE
HARDWARE
