E.3.5 Home > WAN Submenu
Open the WAN submenu from the Home menu. This submenu contains the following options:
Hot
Configuration Page
Key
A
QoS
B
Compression
C
Encryption
Press a hot key to access a configuration page. See the specified appendix section for further
configuration options. Otherwise, press [ESC] to return to the Home menu.
E.3.5.1 Home > WAN > QoS Submenu
Open the QoS (Quality of Service) submenu from the WAN submenu. This submenu contains the
following options:
Hot
Page / Dialog Window
Key
A QoS Max-Pri and Min-Max Table
B
QoS Differentiated Services Table
C
QoS SAR Feature
D QoS Rules Delete All
Press a hot key to open a dialog window. Otherwise, press [ESC] to return to the Network
submenu.
Function
Configure Quality of Service operation
Configure Router Mode compression refresh rates
Configure Managed Switch Mode Encryption and define
Encryption Keys 1 through 8
Description / Option Entry
See Sect. E.3.5.1.1
See Sect. E.3.5.1.2
Use the ↑↓ arrow keys to select Disable or Enable
Use the ↑↓ arrow keys to select No or Yes
E–56
Revision 13
MN-CDM625
Sect.
E.3.5.1
E.3.5.2
E.3.5.3
