CDM-625 Advanced Satellite Modem
Appendix E
Hot
Dialog Window
Key
B Statistics Sample Interval
C Request To Send
D
HSSI Handshake Control
E Circuit ID
F Carrier ID
G
RTC Time
H
RTC Date
I
Tx Clock Source
J
Rx Clock Source
K Rx Buffer Size
L Modem Reference Clock
M G703 Clock Extend Mode
N G703 Clock Extend Intf
O Warm Up Delay
P
Warm Up Countdown
Q
BERT Restart Monitor
R
BERT Tx State
S BERT Tx Pattern
U BERT Rx Pattern
T
BERT Rx State
V BERT 10^-3 Error Insert
W Recenter Buffer
Press a hot key to open a dialog window. Otherwise, press [ESC] to return to the Modem
submenu.
Option Entry
Use the ↑↓ arrow keys to select Disabled, or 10 minutes to 90 minutes
Use the ↑↓ arrow keys to select Loop No Action, Loop RTS Controls
Tx Output, or Ignore RTS Assert CTS
Use the ↑↓ arrow keys to select TA To CA Loop or RR Control CA TA
Control TxS
Enter a Circuit ID value as needed
Use the ↑↓ arrow keys to select Disable or Enable
Enter a value in the form HH:MM:SS
Enter a value in the form DD:MM:YY
Use the ↑↓ arrow keys to select Internal, Tx Terrestrial, Rx Loop
Timed, or Rx Sat
Use the ↑↓ arrow keys to select Rx Satellite, Tx Terrestrial, Internal
SCT, or Insert
Enter a value from 16 to 32768
Use the ↑↓ arrow keys to select:
• Internal • External 1 MHz
• External 5 MHz • External 10 MHz
Use the ↑↓ arrow keys to select None, Tx Lock, or Rx Enable
Use the ↑↓ arrow keys to select T1, E1 Balanced, or E1 Unbalanced
Use the ↑↓ arrow keys to select Disable or Enable
Enter a value from 0 to 999 seconds
Use the ↑↓ arrow keys to select No or Yes
Use the ↑↓ arrow keys to select Off or On
Typical for either entry – Use the ↑↓ arrow keys to select:
• BERT Pattern Space • BERT Pattern Mark
• BERT Pattern 12 • BERT Pattern 63
• BERT Pattern 2047 • BERT Pattern 2047 R • BERT Pattern MIL188
• BERT Pattern 2^15 • BERT Pattern 2^20
Typical for each entry – Use the ↑↓ arrow keys to select Off or On
E–37
Revision 13
MN-CDM625
• External 2 MHz
• Internal Plus Output
• BERT Pattern 11
• BERT Pattern 511
• BERT Pattern 2^23
