CDM-625 Advanced Satellite Modem
Appendix E
E.2 Using the Telnet Command Line Interface (CLI)
In order to use the Telnet CLI to make configuration changes to the CDM-625,
Remote Access Mode should always be set to [Ethernet].
E.2.1 Telnet CLI Menu System – Parallel Functionality
The Telnet CLI allows monitoring, configuration, and control of the CDM-625 Satellite Modem in
a manner similar to functionality provided via its front panel menus and the CDM-625 Web
Server Interface. See those chapters for more in-depth explanations of operation.
•
Chapter 5. FRONT PANEL OPERATION
•
Chapter 6. ETHERNET-BASED REMOTE PRODUCT MANAGEMENT
Certain configuration menu selections (e.g., Carrier-in-Carrier) are functional only
when that FAST feature has been purchased and enabled for operation. This chapter
documents the CLI as if all available options are installed – your configuration may
or may not provide the level of functionality as described in this chapter.
E.2.2 CLI Menus – Common Navigation and Operation Features
1. The CLI organizes operation under a hierarchy of Configuration and Information functions. You
may select a configuration submenu or information page (e.g., Administration, Statistics, etc.)
from this top-level menu, either by typing in the bracketed hot key that preceeds the submenu
name, or by using the ↑↓ arrow keys and pressing ENTER. Each submenu provides nested
dialog windows requiring further action.
2. The bottom of each "screen" shows the possible actions to take.
Home (Main) Menu page:
Submenu or nested pages (e.g., Administration, Statisdtics, etc.):
Dialog windows:
Table pages:
