NS Pre-zoning Mode
The NS Pre-zoning Mode fields are as follows:
Pre-zoned responses Mode

Arbitrated Loop Settings

The Arbitrated Loop Setting fields are as follows:
Table 1-3
Field
Send FAN frames?
Always send RSCN?
Enable CLOSE on OPEN received?
Do Not Allow AL_PA 0x00?
Initialize All Looplets?
Send FAN frames?
Always send RSCN?
Enable CLOSE on OPEN received?
Do Not Allow AL_PA 0x00?
Initialize All Looplets?
Fabric OS Reference
Specify 0 for Standard Mode, or 1 for Pre-zoning On.
Configure Command Arbitrated Loop Settings
Specifies that fabric address notification (FAN) frames be sent to public loop
devices to notify them of their node ID and address. When set to 1, frames are
sent; when set to 0 frames are not sent.
Following the completion of loop initialization, a remote state change
notification (RSCN) is issued when FL_Ports detect the presence of new
devices or the absence of pre-existing devices. When set, a RSCN is issued upon
completion of loop initialization, regardless of the presence or absence of new or
preexisting devices.
If this is set, a CLS is returned immediately to an OPN if no buffers are available.
This is required for TachLite.
This option disallows ALPA values from being 0.
When this is set, all looplets including the ones not in the same zone are always
re-initialized. This is required for certain RAID subsystems to work properly
during failover.
Telnet Commands
Default Range
1 0 or 1
0 0 or 1
0 0 or 1
0 0 or 1
0 0 or 1
1
