2
Error Messages
Table 2-4
Message
DIAG-CMERRTYPE
Err#102A
[centralMemoryTest]
DIAG-CMICKSUM
Err#2036
[cmiTest]
DIAG-CMIDATA
Err#2035
[cmiTest]
DIAG-CMIINVCAP
Err#2034
[cmiTest]
DIAG-CMINOCAP
Err#2033
[cmiTest]
DIAG-CMISA1
Err#2032
[cmiTest]
DIAG-CMNOBUF
Err#1029
[centralMemoryTest]
DIAG-DATA
Err#266E, 306E
[portLoopbackTest,
crossPortTest]
2-10
Diagnostic Error Messages (Continued)
Description
Port got the wrong CMEM error type
CMI message received failed bad
checksum test
CMI data received did not match data
transmitted
Unintended ASIC erroneously got CMI
capture flag
CMI intended receiver ASIC failed to get
CMI capture flag
An attempt to send a CMI message from
ASIC to ASIC failed
Port could not get any buffer
Payload received by port did not match
payload transmitted
Probable Cause Action
ASIC failure Replace mainboard
assembly
ASIC or mainboard Replace mainboard
failure assembly
ASIC or mainboard Replace mainboard
failure assembly
ASIC or mainboard Replace mainboard
failure assembly
ASIC or mainboard Replace mainboard
failure assembly
ASIC failure Replace mainboard
assembly
ASIC failure Replace mainboard
assembly
mainboard, GBIC Replace mainboard
module or fiber cable assembly, GBIC
failure module or fiber
cable
