filterTest

Frame Filter test for Silkworm 3000 ASICs.
Synopsis
filterTest [passCount]
Availability
admin
Description
This command verifies that the Silkworm 3000 ASIC frame level filtering logic including every
type of filter actions:
•
FLTACT_LIST_A - action to handle the subgroup A based filtering
•
FLTACT_LIST_B - action to handle the subgroup B based filtering
•
FLTACT_FROZEN - action to handle the frame frozen process
•
FLTACT_DISCARD - action to discard frame
•
FLTACT_FORWARD - action to forward frame
This command can be run on every port, and send the frame in internal loop back mode. The filter
test requires two different ports in same quadrant due to the fact that the filter logic sits in
transmitter port can not work if frame is sent directory from the embedded port.
In this test, the filter definition covers the following different filtering conditions:
Table 1-7
Number
0
1
2
3
4
5
6
7
8
9
10
11
Operands
This command has the following operand:
passcount
Fabric OS Reference
List of Filter Test Numbers, Definitions, and Action Types
Filter Definition
unconditional match
unconditional match
unconditional match
unconditional match
unconditional match
SCAM no match and ALPA match
SCAM&DCAM match and ALPA match
Zone A match and ALPA match
Zone B match and ALPA match
Zone A&B match and ALPA match
Zone A|B match and ALPA match
Zone A|B match and ALPA match
Specify the number of times to execute this test. The default value is 1. This
operand is optional.
1
Telnet Commands
Action Type
Forward
List A
List B
Frozen
Discard
List A
List A
List A
List B
List B
Frozen
Discard
1-71
