HP StorageWorks 8B - FC Entry Switch Release Note

HP StorageWorks 8B - FC Entry Switch Release Note

Fabric os release notes version 3.0.1b
Hide thumbs Also See for StorageWorks 8B - FC Entry Switch:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Reference Manual, User Manual
release notes
version 3.0.1b
fabric os
www.hp.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the StorageWorks 8B - FC Entry Switch and is the answer not in the manual?

Questions and answers

Related Manuals for HP StorageWorks 8B - FC Entry Switch

Summary of Contents for HP StorageWorks 8B - FC Entry Switch

  • Page 1 release notes version 3.0.1b fabric os www.hp.com...
  • Page 2 Hewlett-Packard shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.

  • Page 3: Table Of Contents

    Contents General Information About This Release......... Overview .
  • Page 4 Requirements and Compatibility Fabric OS ..........Compatibility with Other Products .

  • Page 5: General Information

    General Information About This Release Fabric OS version 3.0.1b firmware runs and delivers the full potential of the FC Entry Switch 8B and FC Switch 8B products. Both switches are 8-port, auto-sensing 2 Gb/Sec and 1 Gb/Sec Fibre Channel switches. Overview This release note includes a brief description of the new features and enhancements made in Fabric OS version 3.0.1b.

  • Page 6: Getting Software Updates

    General Information Getting Software Updates For information on obtaining software updates contact your HP account representative. Fabric OS v3.0.1b Release Notes - 2...

  • Page 7: New Features And Enhancements

    New Features and Enhancements New Features ISL Trunking Interswitch Link (ISL) Trunking is an optionally licensed product (Performance Upgrade (Option 001)) available on the FC Entry Switch 8B and FC Switch 8B products with Fabric OS version 3.0.1b. ISL Trunking is managed using telnet commands or the Web Tools interface. The ISL Trunking feature allows up to four ISLs, connections between two switches through an Expansion Port (E_Port), to merge logically into a single link.

  • Page 8: Speed Auto Negotiation

    New Features and Enhancements Frame Filtering Based Performance Monitoring - Provides frame statistics based on contents of frame. The application of this monitoring can be used to collect statistics based on FC_Type, Logical Unit Number (LUN), and read/write. Reports - An existing report can be selected from a list of reports that are predefined. In some cases, you can supply the object to be monitored and graphed.

  • Page 9: Zoning

    New Features and Enhancements Alarms The following alarm notification methods have been added in Fabric OS version 3.0.1b: • Email Alert - Sends alarms to pre-configured Email addresses. • Remote Agent Notification (RAN) - Sends alarms to remote applications using Fabric Access.

  • Page 10: Telnet Commands

    New Features and Enhancements Routing Tab: The new Routing tab, available from the Admin View, can be used to view the routing table and to set the link cost for the selected ports and static route. For more information, refer to the Web Tools User’s Guide. Trunk Information Tab: The new Trunk Information tab, available from the Admin View, is a read-only tab that displays trunk information.
  • Page 11 New Features and Enhancements • perfShowFilterMonitor • perfShowPortEEMask • fwHelp • fwMailCfg • portCfgTrunkport • switchCfgTrunk • trunkDebug • trunkShow For a detailed description of the telnet commands, refer to the Fabric OS Reference Manual. Fabric OS v3.0.1b Release Notes - 7...

  • Page 12: Documentation

    Documentation MIB Files The following SNMP MIB files are included with Fabric OS version 3.0.1b: Filename Date femib.smiv2 2/15/01 festd.smiv2 2/27/01 v3_OFA.mib 2/15/01 v3_OFE.mib 2/15/01 v3_OSW.mib 7/6//01 v3_OTRP.mib 3/19/01 Fabric Watch Profiles The following Fabric Watch profiles are included with Fabric OS version 3.0.1b: Filename Date fw.enterprise.backbone.errlog...

  • Page 13: Supporting Documentation

    Documentation Supporting Documentation Related product information can be found in the following publications. Those publications with part numbers are provided as printed copies with your product. The FC Entry Switch 8B and FC Switch 8B Documentation CD contains all publications listed in the table below and is also provided with your product.

  • Page 14: Fabric Os

    Requirements and Compatibility Fabric OS Note: Use of blank spaces in path names is not supported in Fabric OS version 3.0.1b. Note: Use of loop diagnostics will disrupt normal fabric operations, and should not be run in a fabric environment. Compatibility with Other Products Fabric OS version 3.0.1b can be installed and run on the FC Entry Switch 8B or FC Switch 8B.

  • Page 15: Hba Compatibility

    Requirements and Compatibility Operating Systems • Windows 95, 98, or 2000 • Windows NT 4.0 RAM (for Windows operating systems) • 128 MB or more of RAM for fabrics comprised of 21 switches or less • 256 MB or more of RAM for fabrics comprised of more than 21 switches Disk space •...

  • Page 16: Fabric Assist

    Limitations Listed below are the limitations for Fabric OS version 3.0.1b. Fabric Assist QuickLoop Fabric Assist mode is not delivered in Fabric OS version 3.0.1b. Automated Testing When running commands from a script, it is recommended that a two second delay be added between each command.
