Telnet Commands

Virtual Channel Settings

The switch enables fine tuning for a specific application, by configuring the parameters for eight
virtual channels. The first two virtual channels are reserved for switch internal functions and are not
available for modification.
The default virtual channel settings have already been optimized for switch performance. Changing
the default values can improve switch performance, but can also degrade performance. Do not
change these settings without fully understanding the effects of the changes.
The Virtual Channel Setting fields are as follows:
Table 1-2
Field
VC Priority 2
VC Priority 3
VC Priority 4
VC Priority 5
VC Priority 6
VC Priority 7
Descriptions of the Virtual Channel Setting fields are as follows:
VC Priority
Switch Operating Mode
The functionality of this parameter is currently not supported.
Zoning Operation Parameters
The Zoning Operation Parameter fields are as follows:
Standard Mode
Disable NodeName Zone Checking
RSCN Transmission Mode
The RSCN Transmission Mode fields are as follows:
End-device RSCN Transmission Mode
1-42
Configure Command Virtual Channel Settings
Specifies the class of frame traffic given priority for a Virtual Channel.
Specify 1 to force the switch to issue interswitch traffic conforming to FCSW, or
specify 0 to enable proprietary interswitch traffic. The default value is 0. This
value must be set to 1 for interoperability.
Specify 1 to disable using Node WWN when specifying nodes in the zone
database, or specify 0 to enable using Node WWN when specifying nodes in the
zone data. The default value is 1. This value must be set to 1 for interoperability.
Specify 0 for RSCN with single PID, 1 for RSCN with multiple PIDs, or 2 Fabric
RSCN.
Default Range
2 2 to 3
2 2 to 3
2 2 to 3
2 2 to 3
3 2 to 3
3 2 to 3
