LSDbShow

Display the FSPF Link State Database.
Synopsis
LSDbShow [domain]
Availability
All users
Description
Use this command to display a link state database record for switches in the fabric.
There are two data structures - the permanently allocated Link State Database Entry and the Link
State Record (LSR) that is allocated when a switch is connected to the fabric. The LSR for domain
'n' describes the links between the switch with domain number 'n' and its neighbor switches. For a
link to be reported in the LSR, the neighbor for that link must be in NB_ST_FULL state.
This command displays the content of both data structures, if the LSR is present.
Without operands, this command displays the whole Link State Database.
The display shows the following fields:
Table 1-12 LSDbShow display fields
Field
Domain
lsrP
earlyAccLSRs
ignoredLSRs
lastIgnored
installTime
lseFlags
uOutIfs
uPathCost
uOldHopCount
uHopsFromRoot
mOutIfs
parent
mPathCos
mHopsFromRoot
lsAge
reserved
Fabric OS Reference
Description
Domain number described by this LSR. A (self) keyword after the
domain number indicates LSR describes the local switch.
Pointer to LSR.
Number of LSRs accepted even though they were not sufficiently
spaced apart.
Number of LSRs not accepted because they were not sufficiently
spaced apart.
Last time an LSR was ignored.
Time this LSR was installed in the database, in seconds since boot.
Internal variable.
Internal variable
Internal variable.
Internal variable.
Internal variable.
Internal variable.
Internal variable.
Internal variable.
Internal variable.
Age, in seconds, of this LSR. An LSR is removed from the
database when its age exceeds 3600 seconds.
Reserved for future use.
