agtcfgShow

Display the SNMP agent configuration.
Synopsis
agtcfgShow
Availability
All users
Description
Use this command to display the configuration of the SNMP agent in the switch. The following
information is displayed:
•
sysDescr - Displays the switch description.
•
sysLocation - Displays the location of the switch.
•
sysContact - Displays the contact information for this switch.
•
swEventTrapLevel - Displays the event trap level. Possible values are:
0 - None
1 - critical
2 - error
3 - warning
4 - informational
5 - debug
Note:
•
authTraps - Displays whether authorization traps are passed to the trap recipient. The
default value is 0 (off), meaning no messages are sent. A value of 1 (on) means that
authorization trap messages are sent to the community IP addresses configured below. For
SNMPv1 and SNMPv2c, this indicates that a request containing a community string is not
known to the agent.
•
There are six communities, each with a respective trap recipient, supported by the agent. The
first three communities are for read-write access (rw) and the last three are for read-only access
(ro).
For an SNMP Management Station to receive a trap generated by the agent, the admin user
must configure a trap recipient IP address of the Management Station.
Community 1: Secret C0de - Displays the IP address for this trap recipient.
Community 2: OrigEquipMfr - Displays the IP address for this trap recipient.
Community 3: private - Displays the IP address for this trap recipient.
Community 4: public - Displays the IP address for this trap recipient.
Community 5: common - Displays the IP address for this trap recipient.
Community 6: FibreChannel - Displays the IP address for this trap recipient.
Note:
Operands None.
Fabric OS Reference
See errshow for more information on the event trap level.
For more information about these SNMP configuration parameters refer to the agtcfgset
command.
