comment
Operands None.
Fabric OS Reference
No_Sync - module receiving light but out of sync
In_Sync - module receiving light and in sync
Laser_Flt - module signaling a laser fault
Port_Flt - port marked faulty
Diag_Flt - port failed diagnostics
Lock_Ref - locking to the reference signal
Testing - running diagnostics
Online - port is up and running
The comment field may be blank, or it may display:
Disabled - port is disabled
Bypassed - port is bypassed (loop only)
Loopback - port is in loopback mode
E_port - fabric port, shows WWN and name of attached switch
F_port - point-to-point port, shows WWN of attached N_port
G_port - point-to-point but not yet E_port or F_port
L_port - loop port, shows number of NL_ports
(Trunk master) - This port is the master port in a group of trunking ports
(Trunk port, master is port #x) - This port is configured as a trunking port, the
master port is port number x.
(upstream) - This E-port is an upstream path towards the principal switch of the
fabric.
(downstream) - This E-port is a downstream path away from the principal switch
of the fabric.
WWN - This is the WWN of the switch connected to the E-port.
"switch_name" - This is the switch name of the connected switch.
