Telnet Commands

portCfgShow

Display port configuration settings.
Synopsis
portCfgShow
Availability
all users
Description
Use this command to display the current configuration of all ports.
The following configuration information is displayed:
•
Port Speed is displayed as 1G, 2G, or AN (when in Auto speed Negotiation mode). This value
is set by the portCfgSpeed command.
•
Trunk Port is displayed as ON when port is set for trunking or blank (..) when trunking is
disabled on the port. This value is set by the portCfgTrunkport command.
•
The Long Distance setting of the port is shown as blank (..) when long distance mode is off, L1
when the link is up to 50Km, or L2 when the link is up to 100Km. This value is set by the
portCfgLongDistance command.
•
Locked L_Port is displayed as ON when port is locked to L_Port only or blank (..) when
L_Port lock mode is disabled (and it behaves as a U_Port). This value is set by the
portCfgLport command.
•
Locked G_Port is displayed as ON when port is locked to G_Port only or blank (--) when
G_Port lock mode is disabled (and it behaves as a U_Port). This command is set by the
portCfgGport command.
•
Disabled E_Port is displayed as ON when port is not allowed to be an E_Port or blank (--)
when the port is allowed to function as an E_Port. This command is set by the portCfgEport
command.
Operands None.
Example To display the configuration settings of ports on a switch:
switch:admin> portCfgShow
Ports
-----------------+--+--+--+--+----+--+--+--+----+--+--+--+----+--+--+--
Speed
Trunk Port
Long Distance
Locked L_Port
Locked G_Port
Disabled E_Port
switch:admin>
See Also
portCfgEport
portCfgGport
portCfgLport
1-174
0 1 2 3 4 5
2G 2G AN AN AN AN 2G 2G
ON ON ON ON ON ON ON ON
L1 L1 .. .. L2 .. .. ..
.. .. .. .. .. .. .. ..
.. .. .. .. .. ON .. ..
.. .. .. .. .. .. .. ..
where AN:AutoNegotiate, ..:OFF, ??:INVALID.
6 7 8 9 10 11
AN AN AN AN
ON ON ON ON
.. .. .. ..
.. .. .. ..
.. .. .. ..
.. .. .. ..
12 13 14 15
1G AN 1G AN
ON ON ON ON
.. .. .. ..
ON .. .. ..
.. ON .. ..
.. .. ON ..
