VLT® AutomationDrive EZ FC 321
Programming Guide
Parameter 8-07 Diagnosis Trigger
Table 415: Parameter 8-07 Diagnosis Trigger
8-07 Diagnosis Trigger
Default value: [0] Disable
Conversion index: –
This parameter has no function for DeviceNet.
Option
[0]*
[1]
[2]
Parameter 8-08 Readout Filtering
Table 416: Parameter 8-08 Readout Filtering
8-08 Readout Filtering
Default value: Size related
Conversion index: –
Use this function if the speed feedback value readouts on the fieldbus fluctuate. Select [1] Motor Data LP-Filter if the function is
required. A power cycle is required for changes to take effect.
Option Name
[0] Motor data Std-Filt.
[1] Motor data LP-Filter

4.9.2 8-1* Ctrl. Word Settings

Parameter 8-10 Control Word Profile
Table 417: Parameter 8-10 Control Word Profile
8-10 Control Word Profile
Default value: Size related
Conversion index: –
Select the interpretation of the control and status words corresponding to the installed fieldbus. Only the selections valid for the
fieldbus installed in slot A are visible in the LCP display. For more guidelines in the selection of [1] PROFIdrive profile, refer to the
Installation Guide for the installed fieldbus.
206 | Danfoss A/S © 2021.08
Parameter type: Option
Data type: Uint8
Name
Disable
Trigger on alarms
Trigger alarm/warn.
Parameter type: Option
Data type: Uint8
Description
Normal fieldbus readouts.
Filtered fieldbus readouts of the following parameters:
•
Parameter 16-10 Power [kW]
•
Parameter 16-11 Power [hp]
• Parameter 16-12 Motor Voltage
•
Parameter 16-14 Motor current
•
Parameter 16-16 Torque [Nm]
• Parameter 16-17 Speed [RPM]
• Parameter 16-22 Torque [%]
•
Parameter 16-25 Torque [Nm] High
Parameter type: Option
Data type: Uint8
Parameter Descriptions
Setup: 2 setups
Change during operation: True
Description
Setup: All setups
Change during operation: True
Setup: All setups
Change during operation: True
AU373327181955en-000101 / 130R1208
