2394 C 138: V FR C
HAPTER O
Configuring PSTN-Dialed
Number
Configuring Call Control
Protocol
ONFIGURATION
To do...
Enter system view
Enter voice view
Enter voice dial program view dial-program
Enter VoFR entity view
Configure a call mode
Configure a channel to the
peer voice gateway
Follow these steps to configure a PSTN-dialed number:
To do...
Enter system view
Enter voice view
Enter voice dial program view dial-program
Enter VoFR entity view
Configure a PSTN-dialed
number in the FRF.11 trunk
mode
Follow these steps to configure a call control protocol:
To do...
Enter system view
Enter serial interface view
Specify the link layer protocol
for interface encapsulation as
frame relay
Enter interface DLCI view
Configure a VoFR call control
protocol on DLCI
n
In the FRF.11 trunk mode, if the VoFR call control protocol is
■
Huawei-compatible, the cid-number of the channel to the destination host
cannot be 4 or 5 because these two CIDs are already occupied by the system. If
the call control protocol is nonstandard-compatible, the cid-number of the
channel to the destination host cannot conflict with any data sub-channel
Use the command...
system-view
voice-setup
entity entity-number vofr
call-mode static
address vofr-static serial
interface-number dlci-number
cid-number
Use the command...
system-view
voice-setup
entity entity-number vofr
trunk-id string
Use the command...
system-view
interface serial
interface-number
link-protocol fr [ ietf |
nonstandard ]
fr dlci dlci-number
vofr { huawei-compatible
[ dce | dte ] |
nonstandard-compatible
signal-channel ccid-no
data-channel dcid-no
[ keepalive ] }
Remarks
-
-
-
-
Required
By default, the dynamic mode
is adopted.
Required
By default, no channel to the
peer voice gateway is
configured.
Remarks
-
-
-
-
Required
By default, no PSTN-dialed
number is configured in the
FRF.11 trunk mode.
Remarks
-
-
Required
By default, the link layer
protocol for interface
encapsulation is PPP.
-
Required
By default, no VoFR call
control protocol is supported.
