2442 C 140: C
HAPTER ALL
S C
ERVICES ONFIGURATION
Network diagram
Figure 702 Network diagram for hunt group
1000
Telephone A1
Router A
1000
Telephone A2
Configuration procedure
1 Configure Router A.
# Configure the voice entity with a higher priority.
<RouterA> system-view
[RouterA] voice-setup
[RouterA-voice] dial-program
[RouterA-voice-dial] entity 1000 pots
[RouterA-voice-dial-entity1000] line 1/0
[RouterA-voice-dial-entity1000] match-template 1000
[RouterA-voice-dial-entity1000] quit
# Configure the voice entity with a lower priority.
[RouterA-voice-dial] entity 1001 pots
[RouterA-voice-dial-entity1001] line 1/1
[RouterA-voice-dial-entity1001] match-template 1000
[RouterA-voice-dial-entity1001] priority 4
# Enable hunt group for the voice subscriber lines.
[RouterA-voice-dial-entity1001] quit
[RouterA-voice-dial] quit
[RouterA-voice] subscriber-line 1/0
[RouterA-voice-line1/0] hunt-group enable
[RouterA-voice-line1/0] quit
[RouterA-voice] subscriber-line 1/1
[RouterA-voice-line1/1] hunt-group enable
[RouterA-voice-line1/1] quit
2 Configure Router B.
# Configure voice entities.
<RouterB> system-view
[RouterB] voice-setup
[RouterB-voice] dial-program
Eth1/0
10.1.1.2 /24
Router B
Eth1/0
10.1.1.1/24
Eth1/1
20.1.1.1 /24
Eth1/0
20.1.1.2 /24
Router C
2000
Telephone B
3000
Telephone C
