Configuring R2 Digital Line Signaling - 3Com MSR 50 Series Configuration Manual

2328 C 134: E1
HAPTER AND
Configuring R2 Digital
Line Signaling
T1 C
ONFIGURATION
Follow these steps to configure R2 digital line signaling:
To do...
Enter system view
Enter E1/T1 interface view
Create a TS set and enable R2
signaling for it
Enter R2 CAS view
Enable the terminating point
to send answer signal
Enable the originating side to
support re-answer signal
processing
Enable the terminating point
to send clear-forward
acknowledgement signal
(clear-back signal)
Enable metering for R2
signaling
Enable the terminating point
to send seizure
acknowledgement signal
Configure the ABCD bit
pattern for each type of R2
line signal
Configure the C and D signal
bits
Configure line signal inversion
mode
Set timeout values of line
signals
Table 88 Default values of signals in R2 digital line signaling
Signal
Answer
Blocking
Clear-back
Clear-forward
Use the command...
system-view
controller { e1 | t1 }
number
timeslot-set ts-set-number
timeslot-list timeslots-list
signal r2
cas ts-set-number
answer enable
re-answer enable
clear-forward-ack enable Optional
force-metering enable
seizure-ack enable
dl-bits { answer | blocking
| clear-back |
clear-forward | idle | seize
| seizure-ack |
release-guard } { receive |
transmit } ABCD
renew ABCD
reverse ABCD
timer dl { answer |
clear-back | clear-forward
| | re-answer |
release-guard | seize }
time
Default rx-bits ABCD
0101
1101
1101
1001
Remarks
-
-
Required
-
Optional
Enabled by default.
Optional
By default, the originating side
does not support processing of
re-answer signals.
Disabled by default.
Optional
Disabled by default.
Optional
Enabled by default.
Optional
See Table 88 for the defaults.
Optional
Optional
The default is 0000, that is, line
signal inversion disabled.
Optional
The default is 60000
milliseconds for answer signal;
10000 milliseconds for
clear-back signal and
clear-forward signal and
release-guard signal; 1000
milliseconds for seizure signal
and re-answer signal.
Default tx-bits ABCD
0101
1101
1101
1001
