Omron DeviceNet CV Series Operation Manual page 39

Starting Communications
1,2,3...
22
Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com
Creating and Registering Scan Lists
Use the following procedure to create, register, and enable the scan lists.
• The following procedure shows how to clear scan lists.
C
S 1
CHG
CHG
1. Switch the operating mode switch to PROGRAM mode.
2. Display the initial screen.
3. Monitor IR 100 (software switches).
4. Turn ON bit 01(Scan List Clear Bit).
5. Monitor IR 101 (Master Status Area 1) and check that bit 09 (scan list op-
eration end) turns ON.
6. Turn OFF bit IR 10001.
• The following procedure shows how to check the registered slave data.
Monitor IR 102 to IR 105 (Registered Slave Data Area), and check that bits
00, 01, 02, 03, 07, and 08 are ON.
The numbers in the following table indicate the node addresses. In the
Registered Slave Data Area, the bits corresponding to the nodes that are
communicating properly are ON.
IR 102
IR 103
IR 104
IR 105
00000
CLR
c100
0 0
O R
0000
c100
2
WRITE WRITE
0002
c100
B200
c100
0
WRITE
0000
Section 2-4
Bit
