Omron DeviceNet CV Series Operation Manual page 350

Using Another Company's Master Unit
Model Produced
connection
size
DRT1-MD32ML 02H
DRT1-MD32ML-1 02H
DRT1-ID16X 02H
DRT1-ID16X-1 02H
DRT1-OD16X 00H
DRT1-OD16X-1 00H
DRT1-HD16S 02H
DRT1-ND16S 01H
DRT1-TS04T 08H
DRT1-TS04P 08H
DRT1-AD04 04H or 08H
DRT1-AD04H 08H
DRT1-DA02 00H
CQM1-DRT21 02H
DRT1-ID04CL 01H
DRT1-ID04CL-1 01H
DRT1-ID08CL 01H
DRT1-ID08CL-1 01H
DRT1-ID08C 01H
DRT1-HD16C 02H
DRT1-HD16C-1 02H
DRT1-OD04CL 00H
DRT1-OD04CL-1 00H
DRT1-OD08CL 00H
DRT1-OD08CL-1 00H
DRT1-OD08C 00H
DRT1-WD16C 00H
DRT1-WD16C-1 00H
DRT1-MD16C 01H
DRT1-MD16C-1 01H
DRT1-B7AC 04H
Device Profile for the C200H I/O Link Unit
General data Compatible DeviceNet Specifications
Header name
Device type name
Manufacturer catalog number
Manufacturer revision
