Omron DeviceNet CV Series Operation Manual page 355

Using Another Company's Master Unit
Item
Object instance 6
(AR Area: AR 00 to AR 27)
See note.
Object instance 7
(TIM/CNT Area: TIM/CNT 000 to
TIM/CNT 511)
See note.
Object instance 8
(EM Area: Depends on the model)
See note.
Note The data areas shown in the table are for C200HX/HG/HE (-ZE) PLCs. Refer to the following table for
the equivalent data areas in CS1H/G PLCs.
C200HX/HG/HE (-ZE)
CIO Area 1 (IR 000 to IR 235)
CIO Area 2 (IR 300 to IR 511)
DM Area (DM 0000 to DM 6143)
LR Area (LR 00 to LR 63)
HR Area (HR 00 to HR 99)
AR Area (AR 00 to AR 27)
TC Area (TC 00 to TC 511)
EM Area (Depends on the model being used.)
Refresh Object (0x92)
Object class Attribute
Service
Item
Object instance 1 Attribute
(current value)
Item
Object instance 1 Service
(current value)
Item
Object instance 2 Attribute
(set value)
338
Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com
DeviceNet service
Service 1C Block String Read
1D Block String N Read
1E Block String Write
1F Block String N Write
Service 1C Block String Read
1D Block String N Read
1E Block String Write
1F Block String N Write
Service 1C Block String Read
1D Block String N Read
1E Block String Write
1F Block String N Write
CIO Area 1 (CIO 000 to CIO 235)
CIO Area 2 (CIO 300 to CIO 511)
Data Memory Area (D0000 to D6143)
No equivalent
Holding Area (H000 to H099)
Holding Area (H100 to H127) (H101 is not allowed.)
Timer PV Area (T000 to T511)
E Area (Depends on the model being used.)
Not supported
Not supported
ID and contents
64: Output refresh bytes
65: Output refresh area type
66: Output refresh address
67: Input refresh bytes
68: Input refresh area type
69: Input refresh address
DeviceNet service
0EGet_Attribute_Single
01Set_Attribute_Single
ID content
64: Output refresh bytes
65: Output refresh area type
66: Output refresh address
67: Input refresh bytes
68: Input refresh area type
69: Input refresh address
Parameter option
Logical Area Address Length
Logical Area Address Length
Logical Area Address
Logical Area Address
Logical Area Address Length
Logical Area Address Length
Logical Area Address
Logical Area Address
Logical Area Address Length
Logical Area Address Length
Logical Area Address
Logical Area Address
CS1H/G
Get Set
(read) (write)
Yes No ---
Yes No ---
Yes No ---
Yes No ---
Yes No ---
Yes No ---
Parameter option
No
No
Get Set
(read) (write)
Yes Yes ---
Yes Yes ---
Yes Yes ---
Yes Yes ---
Yes Yes ---
Yes Yes ---
Appendix B
Value
Value
