Using Another Company's Master Unit
Physical conform- Network current consumption
ance data
Connector type
Physical insulation
Supported indicators
MAC ID setting
Default MAC ID
Baud rate setting
Supported baud rates
Communications Predefined Master/Slave connection set
data
Dynamic connection support (UCMM)
Explicit message fragmentation support
Note For Analog Input Terminals, Analog Output Terminals, and Temperature Input Terminals, Volume I is 1.2
and Volume II is 1.1.
Object Mounting
Identity Object (0x01)
Object class Attribute
Service
Item
Object instance Attribute
326
Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com
Not supported
Not supported
ID content Get (read)
1 Vendor Yes
2 Product type Yes
3 Product code Yes
4 Revision Yes
5 Status (bits supported) Yes
6 Serial number Yes
7 Product name Yes
8 State No
40 mA max. (24 V DC) for the following Units:
CQM1-DRT21, DRT1-HD16S, DRT1-ND16S, and
DRT1-OD08CL
30 mA max. (24 V DC) for the following Units:
DRT1-ID08(-1), DRT1-ID16(-1), DRT1-OD08(-1),
DRT1-OD16(-1), DRT1-ID16T(-1), DRT1-OD16T(-1),
DRT1-MD16T(-1), DRT1-WD16C(-1), DRT1-MD16C(-1),
DRT1-ID16X(-1), DRT1-OD16X(-1), DRT1-AD04,
DRT1-AD04H, DRT1-DA02, DRT1-ID08CL(-1),
DRT1-ID08C, DRT1-HD16C(-1), DRT1-TS04T, and
DRT1-TS04P
25 mA max. (24 V DC) for the following Units:
DRT1-MD16 and DRT1-ID04CL(-1),
50 mA max. (24 V DC) for the following Units:
DRT1-ID16TA(-1), DRT1-OD16TA(-1),
DRT1-MD16TA(-1), and DRT1-ID32ML(-1),
90 mA max. (24 V DC) for the following Unit:
DRT1-OD32ML(-1)
70 mA max. (24 V DC) for the following Units:
DRT1-MD32ML(-1) and DRT1-B7AC
35 mA max. (24 V DC) for the following Unit:
DRT1-OD04CL(-1)
Open plug
Yes
Module, Network
DIP switch
0
DIP switch
125 kbps, 250 kbps, and 500 kbps
Group 2 only server
No
Yes
Set (write)
No 47
No 0
No See note 2.
No 1.3 (See note 1.)
No Bit 0 only
No Unique for each Unit
No Same as the model name.
No ---
Appendix B
Value
