Omron DeviceNet CV Series Operation Manual page 356

Using Another Company's Master Unit
Item
Object instance 2 Service
(set value)
Note The refresh areas are divided as follows:
C200HX/HG/HE (-ZE)
CIO Area 1 (IR 000 to IR 235)
CIO Area 2 (IR 300 to IR 511)
DM Area (DM 0000 to DM 6143)
LR Area (LR 00 to LR 63)
HR Area (HR 00 to HR 99)
AR Area (AR 00 to AR 27)
TC Area (TC 00 to TC 511)
EM or E Area (Only valid with PLC's equipped with Extended Data Memory. Bank 0 only.)
Note Device Profile for the RS-232C Unit
General data Compatible DeviceNet Specifications
Header name
Device type name
Manufacturer catalog number
Manufacturer revision
Physical conform- Network current consumption
ance data
Connector type
Physical insulation
Supported indicators
MAC ID setting
Default MAC ID
Baud rate setting
Supported baud rates
Communications Predefined Master/Slave connection set
data
Dynamic connection support (UCMM)
Explicit message fragmentation support
Object Mounting
Identity Object (0x01)
Object class Attribute
Service
Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com
DeviceNet service
0E Get_Attribute_Single
10 Set_Attribute_Single
01 Get_Attribute_All
02 Set_Attribute_All
CIO Area 1 (CIO 000 to CIO 235)
CIO Area 2 (CIO 300 to CIO 511)
Data Memory Area (D0000 to D6143)
No equivalent
Holding Area (H000 to H099)
Holding Area (H100 to H127) (H101 is not allowed.)
Timer PV Area (T000 to T511)
Not supported
Not supported
No
No
No
No
CS1H/G
Volume I - Release 2.0
Volume II - Release 2.0
OMRON Corporation
Slaves:
Generic
W347
1.0
24 V DC at 50 mA max.
Open plug
Yes
Module, Network
DIP switch
0
DIP switch
125 kbps, 250 kbps, and 500 kbps
Group 2 only server
Yes
Yes
Appendix B
Parameter option
Header ID = 47
Device type number = 0
339
