Temperature Input Terminals
Input classifi-
cation
Note
Data Ranges and the
Open-circuit Detection
Function
Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com
The four inputs occupy four words at the Master, as shown below. If the input
classification is set for up to one digit below the decimal point, a multiple of 10
will be transmitted as binary data.
Beginning word
Beginning word + 1
Beginning word + 2
Beginning word + 3
Unit: 1°C (°F) R, S, K1, J1, E,
L1, N, W, B, PL
Unit: 0.1°C (°F) K2, J2, T, L2, U,
Pt100, JPt100
1. For more details regarding temperature conversion data with a unit setting
of two digits below the decimal point (unit: 0.01), refer to page 164.
2. If there is a sudden temperature change, condensation may develop inside
of the Terminal and cause incorrect values to be displayed. If condensation
does develop, leave the Terminal for approximately one hour at a stable
temperature before using it.
The following table shows the convertible data ranges according to the num-
ber set by the rotary switch.
DRT1-TS04T
Number Input classification
0 R
1 S
2 K1
3 K2
4 J1
5 J2
6 T
7 E
8 L1
9 L2
A U
B N
C W
D B
E PL II
F Cannot be set.
Input 0: Temperature conversion data
Input 1: Temperature conversion data
Input 2: Temperature conversion data
Input 3: Temperature conversion data
850° → 0352 (4 digits hex)
–200° → FF38 (4 digits hex)
x10
500.0° → 5000 → 1388 (4 digits hex)
–20.0° → 200 → FF38 (4 digits hex)
–200.0° → 2000 → F830 (4 digits hex)
Range (°C)
–20 to 1720
–20 to 1720
–220 to 1200
–20.0 to 520.0
–120 to 870
–20.0 to 420.0
–220.0 to 420.0
–20 to 620
–120 to 870
–20.0 to 420.0
–220.0 to 420.0
–220 to 1320
–20 to 2320
80 to 1820
–20 to 1320
Section 4-9
Bit
Range (°F)
–20 to 3020
–20 to 3020
–320 to 2320
–20.0 to 920.0
–120 to 1520
–20.0 to 770.0
–320.0 to 720.0
–20 to 1120
–120 to 1520
–20.0 to 770.0
–320.0 to 720.0
–320 to 2320
–20 to 4120
280 to 3220
–20 to 2320
163
