Temperature Input Terminals
Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com
Item
Shock resistance
Dielectric strength
Insulation resistance
Ambient operating temper-
ature
Ambient operating humidity 35% to 85% (with no condensation)
Ambient operating environ-
ment
Ambient storage tempera-
ture
Mounting method
Mounting strength
Terminal strength
Weight
Input classification
Instruction precision
Conversion period
Temperature conversion
data
Isolation method
Note Less than –100 ° C of K1, T, N:
U, L1, L2:
Less than 200 ° C of R, S:
Less than 400 ° C of B:
(Instruction value ± 0.5% or ± 6 ° C, whichever is larger) ± 1 digit max.
W:
(Instruction value ± 0.5% or ± 4 ° C, whichever is larger) ± 1 digit max.
PL II:
Specification
2
200 m/s
500 V AC for 1 min (between insulated circuits)
20 MΩ min. at 250 V DC (between insulated circuits)
0 to 55°C
No corrosive gases.
−25 to 65°C
M4 screw mounting or 35-mm DIN track mounting
50 N
10 N min. in the DIN Track direction
Pull: 50 N
230 g max.
R, S, K1, K2, J1, J2, T, E,
B, N, L1, L2, U, W, PL II
convertible (4-point com-
mon input class)
(Instruction value ±0.5% or
±2°C, whichever is larger)
±1 digit max. (See note.)
250 ms / 4 pts.
Binary data (4-digit hexadecimal)
Photocoupler isolation between temperature inputs and
communications lines
(Photocoupler isolation between temperature input sig-
nals.)
± 4 ° C ± 1 digit max.
± 4 ° C ± 1 digit max.
± 6 ° C ± 1 digit max.
No regulation
Section 4-9
160 g max.
Pt100, JPt100 convertible
(4-point common input
class)
(Instruction value ±0.5% or
±1°C, whichever is larger)
±1 digit max.
