RS-232C Units
Port Parameters
Port 1 Set all parameters
Data bit length, par-
ity, No. of stop bits
Header code
enable/disable,
delimiter code
enable/disable, flow
control enable/dis-
able
Baud rate
Header code (only
when header code
is enabled)
Delimiter code (only
when delimiter code
is enabled)
No. of bytes
received after the
delimiter (when the
delimiter code is
enabled) or the No.
of bytes received
per frame (when the
delimiter code is
disabled).
Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com
Parameters
Attribute ID, Set Values (Command)
The parameters and set values are set as shown in the following table.
Attribute ID
64 Hex ALL PARAMETER SET (See below)
65 Hex Specify the appropriate set values from the
parameters in the table, as single-byte (2-digit)
hexadecimal. (See note.)
66 Hex
Specify bit data in single-byte (2-digit)
hexadecimal, as shown in the following
diagram.
Bit
Always 0
67 Hex Specified in single-byte (2-digit) hexadecimal
as follows:
00 Hex: 1,200 bps
01 Hex: 2,400 bps
02 Hex: 4,800 bps
03 Hex: 9,600 bps
04 Hex: 19,200 bps
05 to 07 Hex: Not allowed
68 Hex Specifies the header code in single-byte (2-
digit) hexadecimal.
69 Hex Specifies the delimiter code in single-byte (2-
digit) hexadecimal.
6A hex Specifies the number of bytes in single-byte (2-
digit) hexadecimal.
Set values
Header code: 0: Enabled 1: Disabled
Delimiter code: 0: Enabled 1: Disabled
Flow control (RS/CS control)
0: Enabled 1: Disabled
Section 6-2
Initial values
Initial values for
each parameter
Data bit length:
7 bits
Parity: Even
No. of stop bits:
2 bits
Header code and
delimiter code
enabled, flow con-
trol disabled
2,400 bps
02 Hex (STX code)
03 Hex (ETX code)
00 Hex
