Omron DeviceNet CV Series Operation Manual page 99

Transistor Remote I/O Terminals with 3-tier I/O Terminal Blocks
Components of the DRT1-MD16TA and DRT1-MD16TA-1
Rotary switches (Refer to page 62.)
Set the node address.
DIP switch
Pins 1 and 2: Baud rate setting
Pin 3: Reserved (Always OFF.)
Pin 4: Hold/Clear outputs for communications error
DeviceNet Indicators
DRT1-MD16TA
REMOTE TERMINAL DC24V
ON
MS
DR0 DR1 NC HOLD
NS
Communications
connector
Internal Circuits
5
V+
4
CAN_H
3
DRAIN
2
CAN_L
1
V−
82
Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com
(Refer to page 62.)
(Refer to page 312.)
Input indicators
Indicate the output status of each
contact. (Lit when the input is ON.)
0 1 2 3 4 5 6 7 0 1 2
DIN track mounting hooks
Input terminal block
The following diagram shows the internal circuits for the DRT1-MD16TA
Remote I/O Terminal.
Physi-
cal
layer
Internal
circuitry
DC-DC
converter
(Isolated)
Output indicators
Indicate the output status of each contact.
(Lit when the output is ON.)
3 4 5 6 7
IN OUT
Circuit removal screws.
Output terminal block
Photo-
coupler
Voltage
step-down
Photo-
coupler
Section 4-4
V1 24 V DC
G1
V1
0 to 7
G1
V2 24 V DC
G2
V2
0 to 7
G2
