Temperature Input Terminals
Node Address Settings
Note
Baud Rate Setting
Note
4-9-2

Temperature Input Terminals: DRT1-TS04T and DRT1-TS04P

Specifications
158
Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com
Each Slave's node address is set with pins 1 through 6 of the Slave's DIP
switch. Any node address within the setting range can be used as long as it
isn't already set on another node.
DIP switch setting
Pin 6 Pin 5 Pin 4 Pin 3
0 0 0 0
0 0 0 0
0 0 0 0
:
:
1 1 1 1
1 1 1 1
1 1 1 1
1. Refer to Appendix A Node Address Settings Table for a complete table of
DIP switch settings.
2. The Slave won't be able to participate in communications if the same node
address is used for the Master or another Slave node (node address dupli-
cation error).
Pins 7 and 8 are used to set the baud rate as shown in the following table.
(These pins are factory-set to OFF.)
Pin 7 Pin 8
OFF OFF
ON OFF
OFF ON
ON ON
1. Always turn OFF the Slave's power supply (including the communications
power supply) before changing the baud rate setting.
2. Set the same baud rate on all of the nodes (Master and Slaves) in the Net-
work. Any Slaves with baud rates different from the Master's rate won't be
able to participate in communications. Furthermore, a node with an incor-
rect baud rate may cause communications errors between nodes with cor-
rect baud rate settings.
General Specifications
Item
Model
Input type
Input points
Communications power
supply voltage
Internal power supply volt-
age
Current consumption
Noise immunity
Vibration resistance
Node address
Pin 2 Pin 1
0 0 0 (default)
0 1 1
1 0 2
:
:
0 1 61
1 0 62
1 1 63
Baud rate
125 kbps (default)
250 kbps
500 kbps
Not allowed.
Specification
DRT1-TS04T
Thermocouple input
4 points (allocated four words in the Master Unit.)
11 to 25 V DC (supplied from the communications con-
nector)
20.4 to 26.4 V DC (24 V DC −15% to 10%)
Communications: 30 mA max.
Internal circuit: 130 mA max.
±1.5 kV pulse width: 0.1 to 1 μs, pulse rise time: 1 ns
p-p,
(via noise simulator)
10 to 55 Hz, 1.0-mm double amplitude
Section 4-9
DRT1-TS04P
Resistance temperature
sensor input
