Transistor Remote I/O Terminals with Connectors
Dimensions
4-5-3 Transistor Remote Output Terminals with 32 Points and
Connectors: DRT1-OD32ML (NPN) and DRT1-OD32ML-1 (PNP)
Output Specifications
Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com
The following diagram shows the dimensions for the DRT1-ID32ML and
DRT1-ID32ML-1 Remote Input Terminals. All dimensions are in mm.
Note There are restriction when using the 32-point Transistor Remote Input Termi-
nals with Connectors depending on the ambient operating temperature.
• If the Terminals are not mounted facing up, they can be mounted side-by-
side and all inputs can be turned ON simultaneously at 55 ° C or less.
• If the Terminals are mounted facing up, the distances and temperatures in
the graph given below must be maintained to enable turning ON all inputs
simultaneously. For example, at an ambient temperature of 55 ° C, the Ter-
minals must be separated by at least 10 mm.
Item
Model
Internal I/O common
Output points
Rated output current
Residual voltage
(83)
Values in parentheses
are reference values.
35
30
20
L L
10
0
40 45
Ambient operating temp. ( ° C)
Specification
DRT1-OD32ML
NPN
32 points
0.3 A/point, 4 A/common (see note)
1.2 V max. (at 0.3 A,
between each output termi-
nal and G)
Section 4-5
60
27.8
50 55
DRT1-OD32ML-1
PNP
1.2 V max. (at 0.3 A,
between each output termi-
nal and V)
