Omron DeviceNet CV Series Operation Manual page 364

Connectable Devices and Device Current Consumptions
Connectors
Crimp Terminals for Communications Cables
Note The solderless (crimp) terminals made by Nichifu Co., Ltd. are sold through the OMRON 24 Service Co.,
Ltd. Contact the Nichifu Co., Ltd. directly for details on their products.
Specialty Screwdrivers for Connectors
Terminating Resistors
Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com
Model
MSTB2.5/5-ST-5.08AU
Without connector set screws
(Included with the DRT1-@D08(-1), DRT1-
@D16(-1), DRT1-@D16X(-1), DRT1-@D16S(-
1), DRT1-AD04(H), DRT1-DA02, and DRT1-
TS04@)
XW4B-05C1-H1-D
With connector set screws
(Included with the DRT1-@D16T(-1),
DRT1-@D32ML(-1), CVM1-DRM21-V1,
C200HW-DRM21-V1, CQM1-DRT21, and
DCN1)
XW4B-05C4-T-D
Without connector set screws
XW4B-05C4-TF-D
With connector set screws
Model
TC series:
TME TC-0.5 (for thin cable)
TME TC-2-11 (power supply
wire for thick cable)
TME TC-1.25-11 (communi-
cations wire for thick cable)
AI series:
AI-0.5-8WH-B (product num-
ber 3201369)
AI series:
AI-TWIN2×0.5-8WH (product
number 3200933)
Model
XW4Z-00C Special screwdriver for DeviceNet connectors
SZF-1 Special screwdriver for DeviceNet connectors
Model
Terminal-block Terminating Resistor, 121 Ω
DRS1-T
DRS2-1 Shielded Terminating Resistor (male plug)
DRS2-2 Shielded Terminating Resistor (female socket)
Note Also can be used as Terminating Resistor with T-branch Tap.
Specifications
For node connection
For T-branch Tap and node connection
For node connection (Multi-drop wiring)
For node connection (Multi-drop wiring)
Crimper
NH-32 For single wire
insertion
ZA3 For single wire
insertion
UD6 (product number For two-wire
1204436) insertion
(Multi-drop use)
Specifications
Specifications
Appendix C
Manufacturer
Phoenix Contact
GmbH & Co.
OMRON
OMRON
OMRON
Remarks Manufacturer
Nichifu Co., Ltd.
(See note.)
Phoenix Contact
GmbH & Co.
Manufacturer
OMRON
OMRON Tsufo
Service
Manufacturer
OMRON
347
