Transistor Remote I/O Terminals with Connectors
Mounting Bracket
Dimensions
4-5-6

Wiring Internal Power Supplies, I/O Power Supplies and I/O

Connecting to I/O
Terminals Using OMRON
MIL Cables
Slave
DRT1-ID32ML G79-I50-25-D1 (50 cm)
G79-I75-50-D1 (75 cm)
DRT1-OD32ML G79-O50-25-D1 (50 cm)
G79-O75-50-D1 (75 cm)
108
Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com
Mounted to Parallel to a Panel
The dimensions of the SRT2-ATT02 Mounting Bracket B are shown below.
7.3
Internal power is supplied together with the communications power supply
and does not need to be wired separately. I/O power supplies and I/O are
wired through the I/O MIL connector.
The MIL Cables listed in the following table are available to connect OMRON
I/O Terminals (e.g., I/O Relay Blocks). Select the MIL Cable that matches the
Remote I/O Terminal and the I/O Terminal.
MIL Cable I/O Relay Block or other I/O
G7TC-ID16
G7TC-IA16
G7TC-OC08/OC16
G70D-SOC16/VSOC16
G70A-ZOC16-3
G70D-FOM16/VFOM16
Mounting
Bracket B
0.1 mm
Mounting holes
32.5
Terminal
Section 4-5
Two, 3.2 dia. or M3
Remarks
