Omron DeviceNet CV Series Operation Manual page 133

Remote Adapters
Dimensions
(With connector attached)
Mounting holes
116
Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com
Input Devices
Use a printed circuit board to wire I/O devices to a flat cable MIL plug which
can be connected to the Remote Adapter.
NPN output 3-wire sensor
(photoelectric or proximity sensor)
2-wire sensor
(limit switch)
I/O power supply
Note In accordance with the changes in the standards for photoelectric sensors
and proximity sensors, wire colors have been changed. Colors in parentheses
are the old wire colors.
The following diagram shows the dimensions for the DRT1-ID16X and DRT1-
ID16X-1 Remote Input Adapters. All dimensions are in mm.
Flat cable length: Approx. 60
85 max.
Two, 4.2 dia. or M4
±
75 0.3
Brown
Top View
(red)
Black
(white)
Blue
(black)
Brown
(white)
Blue
(black)
–
+
Connector pin No.
Approx. 73
40 max.
Section 4-6
▲ Triangle mark
