Temperature Input Terminals
Rotary Switch Setting
Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com
Set the common input classification and input signal range for each input with
the rotary switch. (The input classification and input range cannot be set for 4-
point classification.)
Note Always turn OFF the Slave's power supply (including the communications
power supply) before changing any settings.
DRT1-TS04T
The following table shows the input classifications and input ranges according
to the rotary switch settings.
Number Input classification
0 R
1 S
2 K1
3 K2
4 J1
5 J2
6 T
7 E
8 L1
9 L2
A U
B N
C W
D B
E PL II
F Cannot be set.
DRT1-TS04P
The following table shows the input classifications and input ranges according
to the rotary switch settings.
Number Input classification
0 PT100
1 JPT100
2 to 9 Cannot be set.
Section 4-9
Range (°C) Range (°F)
0 to 1700 0 to 3000
0 to 1700 0 to 3000
–200 to 1300 –300 to 2300
0.0 to 500.0 0.0 to 900.0
–100 to 850 –100 to 1500
0.0 to 400.0 0.0 to 750.0
–200.0 to 400.0 –300.0 to 700.0
0 to 600 0 to 1100
–100 to 850 –100 to 1500
0.0 to 400.0 0.0 to 750.0
–200.0 to 400.0 –300.0 to 700.0
–200 to 1300 –300 to 2300
0 to 2300 0 to 4100
100 to 1800 300 to 3200
0 to 1300 0 to 2300
Range (°C) Range (°F)
–200.0 to 650.0 –300.0 to 1200.0
–200.0 to 650.0 –300.0 to 1200.0
