Transistor Remote I/O Terminals with 3-tier I/O Terminal Blocks
Dimensions
DRT1-OD16T
REMOTE TERMINAL DC24V
ON
MS
DR0 DR1 NC HOLD
NS
Mounting holes
Two, 4.2 dia. or M4
4-4-5 Transistor Remote Output Terminals with 16 Points and 3-tier I/O
Terminal Blocks: DRT1-OD16TA (NPN) and DRT1-OD16TA-1 (PNP)
Output Specifications
Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com
The following diagram shows the dimensions for the DRT1-OD16T and DRT1-
OD16T-1 Remote Output Terminals. All dimensions are in mm.
180
0 1 2 3 4 5 6 7 8 9
0 1 2 3 4 5 6 7 8
170±0.2
Note The circuit section can be removed by loosening the circuit removal screws.
(Refer to Components of the DRT1-OD16T and DRT1-OD16T-1. )
Always turn OFF the communications, internal, and I/O power supplies before
removing or attaching the circuit section.
Item
Model
Internal I/O common
Output points
Rated output current
Residual voltage
Leakage current
ON delay time
OFF delay time
Number of circuits
10 11 12 13 14 15
OUT
9 10 11 12 13 14 15
Specification
DRT1-OD16TA
NPN
16 points
0.5 A/point
1.2 V max. (at 0.5 A,
between each output termi-
nal and G)
0.1 mA max.
0.5 ms max.
1.5 ms max.
8 points
Section 4-4
58
(83)
Values in parentheses
are reference values.
DRT1-OD16TA-1
PNP
1.2 V max. (at 0.5 A,
between each output termi-
nal and V)
73
