Omron DeviceNet CV Series Operation Manual page 243

B7AC Interface Units
Tables of Compatible Connectors
226
Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com
A
NC
Connector 3
(Port A)
Connector 4
(Port B)
Connector 1 (DeviceNet Communications Connector)
Connector type
Cable with shielded connec-
tors on both ends
Cable with shielded connector
(socket) on one end
Cable with shielded connector
(plug) on one end
Shielded T-branch connector
Connector 2 (Connector for Power Supply to Internal Circuitry)
Connector type
Cable with connectors on both
ends (socket and plug)
Cable with connector on one
end (female socket)
Connector socket assembly
(female)
(Crimp-connector or solder
type)
T-joint
Connector 1
(DeviceNet communications
connector)
ERR A ERR B ERR C MS NS
C
B P
Connector 2
(Connector for power supply
to internal circuitry)
Connector 5
(Port C)
Model
DCA1-5CN@@W1
Plug
(male)
DCA1-5CN@@F1
Socket
(female)
DCA1-5CN@@H1
Plug
(male)
DCN2-1
Socket
(female)
Model
XS2W-D42@-@81-@
Plug
(male)
XS2F-D42@-@80-@
Socket
(female)
XS2C-D4@@
XS2R-D427-5
Socket
(female)
Section 5-5
Appearance
Socket
(female)
Socket
(female)
Plug
(male)
Appearance
Socket
(female)
Socket
(female)
Socket
(female)
Plug
(male)
