Baud Rate and Hold/Clear Write Area Settings (Front DIP Switch)

Baud Rate
Note
6-1-4

Specifications

General Specifications
Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com
The DIP switch on the front panel of the Unit is used to set the baud rate and
Hold/Clear Write Area data for communications error. The functions and set-
ting for the front panel DIP switch are as shown in the following diagram.
Pin
1 Baud rate
2
3 Hold/Clear Write Area data for com-
munications error
4 Reserved
Pins 1 and 2 are used to set the baud rate as shown in the following table.
Pin 1 Pin 2
OFF OFF 125 kbps (default)
ON OFF 250 kbps
OFF ON 500 kbps
ON ON Not allowed.
1. Always turn OFF the Slave's power supply (including the communications
power supply) before changing the baud rate setting.
2. Set the same baud rate on all of the nodes (Master and Slaves) in the Net-
work. Any Slaves with baud rates different from the Master's rate will not
be able to participate in communications, and may cause communications
errors to occur between nodes with correct baud rate settings.
Item
Model
Connectable PLCs
Communications power
supply voltage
Internal current con-
sumption
Mounting
Weight
Note All other specifications except those listed correspond to those of the
C200HX/HG/HE PLCs.
Reserved (Always OFF.)
Hold/Clear Write Area data for communications error
Baud rate
Function
See the next table.
OFF:
ON:
Leave this pin set to OFF.
Baud rate
Specification
C200HW-DRT21
CS1H/G, C200HX/HG/HE(-Z)
11 to 25 V DC
(Supplied from the communications connector.)
Communications: 45 mA max.
Internal circuits: 250 mA max. (5 V DC supplied via PLC's
Backplane.)
Mounted on a CS1H/G or C200HX/HG/HE Backplane.
250 g max.
Section 6-1
Setting
Clear (default)
Hold
