C8051F120/1/2/3/4/5/6/7 C8051F130/1/2/3

SFR Definition 6.5. ADC0H: ADC0 Data Word MSB

0
SFR Page:
0xBF
SFR Address:
R/W R/W
Bit7 Bit6
Bits7–0: ADC0 Data Word High-Order Bits.
For AD0LJST = 0: Bits 7–4 are the sign extension of Bit3. Bits 3–0 are the upper 4 bits of the
10-bit ADC0 Data Word.
For AD0LJST = 1: Bits 7–0 are the most-significant bits of the 10-bit ADC0 Data Word.

SFR Definition 6.6. ADC0L: ADC0 Data Word LSB

0
SFR Page:
0xBE
SFR Address:
R/W R/W
Bit7 Bit6
Bits7–0: ADC0 Data Word Low-Order Bits.
For AD0LJST = 0: Bits 7–0 are the lower 8 bits of the 10-bit ADC0 Data Word.
For AD0LJST = 1: Bits 7–4 are the lower 4 bits of the 10-bit ADC0 Data Word. Bits 3–0 will
always read '0'.
82
R/W R/W R/W
Bit5 Bit4 Bit3
R/W R/W R/W
Bit5 Bit4 Bit3
Rev. 1.4
R/W R/W R/W
Bit2 Bit1 Bit0
R/W R/W R/W
Bit2 Bit1 Bit0
Reset Value
00000000
Reset Value
00000000
