C8051F120/1/2/3/4/5/6/7 C8051F130/1/2/3

SFR Definition 10.2. CPT0MD: Comparator0 Mode Selection

1
SFR Page:
0x89
SFR Address:
R/W R/W
- - CP0RIE
Bit7 Bit6
Bits7–6: UNUSED. Read = 00b, Write = don't care.
Bit 5: CP0RIE: Comparator 0 Rising-Edge Interrupt Enable Bit.
0: Comparator 0 rising-edge interrupt disabled.
1: Comparator 0 rising-edge interrupt enabled.
Bit 4: CP0FIE: Comparator 0 Falling-Edge Interrupt Enable Bit.
0: Comparator 0 falling-edge interrupt disabled.
1: Comparator 0 falling-edge interrupt enabled.
Bits3–2: UNUSED. Read = 00b, Write = don't care.
Bits1–0: CP0MD1–CP0MD0: Comparator0 Mode Select
These bits select the response time for Comparator0.
Mode
0
1
2
3
R/W R/W R/W
CP0FIE
Bit5 Bit4 Bit3
CP0MD1 CP0MD0
0 0
0 1
1 0
1 1 Lowest Power Consumption
R/W R/W
- - CP0MD1 CP0MD0 00000010
Bit2 Bit1
Notes
Fastest Response Time
—
—
Rev. 1.4
R/W Reset Value
Bit0
123
