C8051F120/1/2/3/4/5/6/7 C8051F130/1/2/3
R/W
R/W
P6.7
P6.6
Bit7
Bit6
Bits7–0: P6.[7:0]: Port6 Output Latch Bits.
Write - Output appears on I/O pins.
0: Logic Low Output.
1: Logic High Output (Open-Drain if corresponding P6MDOUT bit = 0). See SFR Definition
18.18.
Read - Returns states of I/O pins.
0: P6.n pin is logic low.
1: P6.n pin is logic high.
Note:
P6.[7:0] can be driven by the External Data Memory Interface (as Address[15:8] in Multiplexed
mode, or as Address[7:0] in Non-multiplexed mode). See
Memory Interface and On-Chip XRAM" on page 219
External Memory Interface.
SFR Definition 18.18. P6MDOUT: Port6 Output Mode
R/W
R/W
Bit7
Bit6
Bits7–0: P6MDOUT.[7:0]: Port6 Output Mode Bits.
0: Port Pin output mode is configured as Open-Drain.
1: Port Pin output mode is configured as Push-Pull.
256
SFR Definition 18.17. P6: Port6 Data
R/W
R/W
R/W
P6.5
P6.4
P6.3
Bit5
Bit4
Bit3
R/W
R/W
R/W
Bit5
Bit4
Bit3
Rev. 1.4
R/W
R/W
R/W
P6.2
P6.1
P6.0
Bit2
Bit1
Bit0
SFR Address:
SFR Page:
Section "17. External Data
for more information about the
R/W
R/W
R/W
Bit2
Bit1
Bit0
SFR Address:
SFR Page:
Reset Value
11111111
Bit
Addressable
0xE8
F
Reset Value
00000000
0x9E
F
