Sfr Definition 23.5. Tl1: Timer 1 Low Byte; Sfr Definition 23.6. Th0: Timer 0 High Byte; Sfr Definition 23.7. Th1: Timer 1 High Byte - Silicon Laboratories C8051F12 Series Manual

C8051F120/1/2/3/4/5/6/7 C8051F130/1/2/3
R/W R/W
Bit7 Bit6
Bits 7–0: TL1: Timer 1 Low Byte.
The TL1 register is the low byte of the 16-bit Timer 1.

SFR Definition 23.6. TH0: Timer 0 High Byte

R/W R/W
Bit7 Bit6
Bits 7–0: TH0: Timer 0 High Byte.
The TH0 register is the high byte of the 16-bit Timer 0.

SFR Definition 23.7. TH1: Timer 1 High Byte

R/W R/W
Bit7 Bit6
Bits 7–0: TH1: Timer 1 High Byte.
The TH1 register is the high byte of the 16-bit Timer 1.
316

SFR Definition 23.5. TL1: Timer 1 Low Byte

R/W R/W
Bit5 Bit4
R/W R/W
Bit5 Bit4
R/W R/W
Bit5 Bit4
Rev. 1.4
R/W R/W R/W
Bit3 Bit2 Bit1
R/W R/W R/W
Bit3 Bit2 Bit1
R/W R/W R/W
Bit3 Bit2 Bit1
R/W Reset Value
00000000
Bit0
0x8B
SFR Address:
SFR Page: 0
R/W Reset Value
00000000
Bit0
0x8C
SFR Address:
SFR Page: 0
R/W Reset Value
00000000
Bit0
0x8D
SFR Address:
SFR Page: 0
