C8051F120/1/2/3/4/5/6/7 C8051F130/1/2/3
The Temperature Sensor transfer function is shown in Figure 6.2. The output voltage (V
input when the Temperature Sensor is selected by bits AMX0AD3-0 in register AMX0SL; this voltage will
be amplified by the PGA according to the user-programmed PGA settings. Typical values for the Slope and
Offset parameters can be found in Table 6.1.

Figure 6.2. Typical Temperature Sensor Transfer Function

74
V
TEMP
Temp
C
-50 0
Temperature (Celsius)
Rev. 1.4
Slope (V / deg C)
Offset (V at 0 Celsius)
= (Slope x Temp ) + Offset
C
= (V - Offset) / Slope
TEMP
50 100
) is the PGA
TEMP
