C8051T620/1/6/7 & C8051T320/1/2/3

SFR Definition 8.2. ADC0H: ADC0 Data Word MSB

Bit 7
Name
Type
0
Reset
SFR Address = 0xBE
Bit Name
7:0 ADC0H[7:0] ADC0 Data Word High-Order Bits.
For AD0LJST = 0: Bits 7–2 will read 000000b. Bits 1–0 are the upper 2 bits of the 10-
bit ADC0 Data Word.
For AD0LJST = 1: Bits 7–0 are the most-significant bits of the 10-bit ADC0 Data
Word.
Note: In 8-bit mode AD0LJST is ignored, and ADC0H holds the 8-bit data word.

SFR Definition 8.3. ADC0L: ADC0 Data Word LSB

Bit 7
Name
Type
0
Reset
SFR Address = 0xBD
Bit Name
7:0 ADC0L[7:0] ADC0 Data Word Low-Order Bits.
For AD0LJST = 0: Bits 7–0 are the lower 8 bits of the 10-bit Data Word.
For AD0LJST = 1: Bits 7–6 are the lower 2 bits of the 10-bit Data Word. Bits 5–0 will
read 000000b.
Note: In 8-bit mode AD0LJST is ignored, and ADC0L will read back 00000000b.
50
6 5 4
ADC0H[7:0]
0 0 0
6 5 4
0 0 0
Rev. 1.2
3 2
R/W
0 0
Function
3 2
ADC0L[7:0]
R/W
0 0
Function
1 0
0 0
1 0
0 0
