Sfr Definition 8.3. Dac0Cn: Dac0 Control - Silicon Laboratories C8051F12 Series Manual

C8051F120/1/2/3/4/5/6/7 C8051F130/1/2/3
R/W R/W
DAC0EN -
Bit7 Bit6
Bit7: DAC0EN: DAC0 Enable Bit.
0: DAC0 Disabled. DAC0 Output pin is disabled; DAC0 is in low-power shutdown mode.
1: DAC0 Enabled. DAC0 Output pin is active; DAC0 is operational.
Bits6–5: UNUSED. Read = 00b; Write = don't care.
Bits4–3: DAC0MD1–0: DAC0 Mode Bits.
00: DAC output updates occur on a write to DAC0H.
01: DAC output updates occur on Timer 3 overflow.
10: DAC output updates occur on Timer 4 overflow.
11: DAC output updates occur on Timer 2 overflow.
Bits2–0: DAC0DF2–0: DAC0 Data Format Bits:
000: The most significant nibble of the DAC0 Data Word is in DAC0H[3:0], while the least
significant byte is in DAC0L.
DAC0H
001: The most significant 5-bits of the DAC0 Data Word is in DAC0H[4:0], while the least
significant 7-bits are in DAC0L[7:1].
DAC0H
MSB
010: The most significant 6-bits of the DAC0 Data Word is in DAC0H[5:0], while the least
significant 6-bits are in DAC0L[7:2].
DAC0H
MSB
011: The most significant 7-bits of the DAC0 Data Word is in DAC0H[6:0], while the least
significant 5-bits are in DAC0L[7:3].
DAC0H
MSB
1xx: The most significant 8-bits of the DAC0 Data Word is in DAC0H[7:0], while the least
significant 4-bits are in DAC0L[7:4].
DAC0H
MSB
108

SFR Definition 8.3. DAC0CN: DAC0 Control

R/W R/W
- DAC0MD1 DAC0MD0 DAC0DF2 DAC0DF1 DAC0DF0 00000000
Bit5 Bit4
MSB
Rev. 1.4
R/W R/W R/W
Bit3 Bit2 Bit1
DAC0L
DAC0L
DAC0L
DAC0L
DAC0L
LSB
R/W Reset Value
Bit0
SFR Address: 0xD4
SFR Page: 0
LSB
LSB
LSB
LSB
