C8051F120/1/2/3/4/5/6/7 C8051F130/1/2/3
R/W
R/W
P4.7
P4.6
Bit7
Bit6
Bits7–0: P4.[7:0]: Port4 Output Latch Bits.
Write - Output appears on I/O pins.
0: Logic Low Output.
1: Logic High Output (Open-Drain if corresponding P4MDOUT.n bit = 0). See SFR Definition
18.14.
Read - Returns states of I/O pins.
0: P4.n pin is logic low.
1: P4.n pin is logic high.
Note:
P4.7 (/WR), P4.6 (/RD), and P4.5 (ALE) can be driven by the External Data Memory Interface.
See
Section "17. External Data Memory Interface and On-Chip XRAM" on page 219
more information.
SFR Definition 18.14. P4MDOUT: Port4 Output Mode
R/W
R/W
Bit7
Bit6
Bits7–0: P4MDOUT.[7:0]: Port4 Output Mode Bits.
0: Port Pin output mode is configured as Open-Drain.
1: Port Pin output mode is configured as Push-Pull.
254
SFR Definition 18.13. P4: Port4 Data
R/W
R/W
R/W
P4.5
P4.4
P4.3
Bit5
Bit4
Bit3
R/W
R/W
R/W
Bit5
Bit4
Bit3
Rev. 1.4
R/W
R/W
R/W
P4.2
P4.1
P4.0
Bit2
Bit1
Bit0
SFR Address:
SFR Page:
R/W
R/W
R/W
Bit2
Bit1
Bit0
SFR Address:
SFR Page:
Reset Value
11111111
Bit
Addressable
0xC8
F
for
Reset Value
00000000
0x9C
F
