Parameter Description

3.15 Parameters 16-** Data Readouts

16-00 Control Word
Range:
3 3
0 [0 - 65535 ] View the Control word sent from the
*
16-01 Reference [Unit]
Range:
0 ReferenceFeed-
backUnit
*
16-02 Reference [%]
Range:
0 % [-200 - 200 %]
*
16-03 Status Word
Range:
0 [0 - 65535 ] View the Status word sent from the adjustable
*
16-05 Main Actual Value [%]
Range:
0 % [-100 - 100 %]
*
16-09 Custom Readout
Range:
0 CustomRea-
doutUnit
*
3.15.1 16-1* Motor Status
16-10 Power [kW]
Range:
0 kW [0 -
*
10000 kW]
3-98
VLT
Function:
adjustable frequency drive via the serial
communication port in hex code.
Function:
[-999999 - 999999 View the present
ReferenceFeed- reference value applied
backUnit] on impulse or analog
basis in the unit
resulting from the
configuration selected
in 1-00 Configuration
Mode (Hz, Nm or RPM).
Function:
Function:
frequency drive via the serial communication
port in hex code.
Function:
Function:
[-999999.99 - View the user-defined
999999.99 readouts as defined in
CustomRea- 0-30 Custom Readout Unit,
doutUnit] 0-31 Custom Readout Min
Value and 0-32 Custom
Readout Max Value.
Function:
Displays motor power in kW. The value
shown is calculated on the basis of the actual
motor voltage and motor current. The value
is filtered, and therefore approx. 30 ms may
pass from when an input value changes to
MG20O622 - VLT
®
AQUA Drive Programming Guide
16-10 Power [kW]
Range:
16-11 Power [hp]
Range:
0 hp [0 - 10000
*
hp]
16-12 Motor voltage
Range:
0 V [0 - 6000 V] View the motor voltage, a calculated value
*
16-13 Frequency
Range:
0 Hz [0 - 6500 Hz] View the motor frequency, without
*
16-14 Motor current
Range:
0 A [0 - 10000
*
A]
16-15 Frequency [%]
Range:
0 %
*
16-16 Torque [Nm]
Range:
0 [-30000 -
Nm 30000
*
Nm]
®
is a registered Danfoss trademark
Function:
when the data readout values change. The
resolution of readout value on serial
communication bus is in 10 W steps.
Function:
View the motor power in HP. The value
shown is calculated on the basis of the
actual motor voltage and motor current. The
value is filtered, and therefore approximately
30 ms may pass from when an input value
changes to when the data readout values
change.
Function:
used for controlling the motor.
Function:
resonance dampening.
Function:
View the motor current measured as a mean
value, I . The value is filtered, and thus
RMS
approximately 30 ms may pass from when
an input value changes to when the data
readout values change.
Function:
[-100 - 100 %]
Function:
View the torque value with sign, applied to
the motor shaft. Linearity is not exact
between 110% motor current and torque in
relation to the rated torque. Some motors
supply more than 160% torque.
Consequently, the min. value and the max.
value will depend on the max. motor current
as well as the motor used. The value is
filtered, and thus approx. 1.3 s may pass from
when an input changes value to when the
data readout values change.
