Parameter Description
0-30 Custom Readout Unit
Option:
[120] GPM
3 3
[121] gal / sec.
[122] gal/min
[123] gal / hr.
[124] CFM
[125] ft³/s
[126] ft³/min
[127] ft³/h
[130] lbs / sec.
[131] lbs / min.
[132] lbs / hr.
[140] ft/s
[141] ft/min
[145] ft
[160] °F
[170] psi
[171] lb/in²
[172] in. wtr. gage
[173] ft WG
[174] in Hg
[180] HP
0-31 Custom Readout Min Value
Range:
Size [ 0.00 - 100.00
related CustomRea-
*
doutUnit]
0-32 Custom Readout Max Value
Range:
100 CustomRea-
doutUnit
*
3-10
VLT
Function:
Function:
This parameter allows the choice
of the min. value of the custom
defined readout (occurs at zero
speed). It is only possible to select
a value different to 0 when
selecting a linear unit in
0-30 Custom Readout Unit. For
quadratic and cubic units, the
minimum value will be 0.
Function:
[ par. 0-31 - This parameter sets the max
999999.99 value to be shown when
CustomRea- the speed of the motor has
doutUnit] reached the set value for
4-13 Motor Speed High Limit
[RPM] or 4-14 Motor Speed
High Limit [Hz] (depends on
setting in 0-02 Motor Speed
Unit).
MG20O622 - VLT
®
AQUA Drive Programming Guide
0-37 Display Text 1
Range:
0 [0 -
*
0 ]
0-38 Display Text 2
Range:
0 [0 -
*
0 ]
0-39 Display Text 3
Range:
0 [0 -
*
0 ]
®
is a registered Danfoss trademark
Function:
In this parameter, it is possible to write an individual
text string for display in the LCP or to be read via
serial communication. If it is to be displayed
permanently, select Display Text 1 in 0-20 Display
Line 1.1 Small, 0-21 Display Line 1.2 Small, 0-22 Display
Line 1.3 Small, 0-23 Display Line 2 Large or
▲
0-24 Display Line 3 Large. Press [
◀ ▶
character. Press [ ] and [ ] to move the cursor.
When a character is highlighted by the cursor, it can
▲ ▼
be changed. Press [ ] or [ ] to change a character.
A character can be inserted by placing the cursor
between two characters and pressing [
Function:
In this parameter, it is possible to write an individual
text string for display in the LCP or to be read via
serial communication. If to be displayed permanently
select Display Text 2 in 0-20 Display Line 1.1 Small,
0-21 Display Line 1.2 Small, 0-22 Display Line 1.3 Small,
0-23 Display Line 2 Large or 0-24 Display Line 3 Large.
▲ ▼
Press [ ] or [ ] to change a character. Press [
▶
[ ] to move the cursor. When a character is
highlighted by the cursor, this character can be
changed. A character can be inserted by placing the
cursor between two characters and pressing [
▼
[ ].
Function:
In this parameter, it is possible to write an individual
text string for display in the LCP or to be read via
serial communication. If it is to be displayed
permanently, select Display Text 3 in 0-20 Display
Line 1.1 Small,0-21 Display Line 1.2 Small, 0-22 Display
Line 1.3 Small, 0-23 Display Line 2 Large or
▲
0-24 Display Line 3 Large. Press [
◀ ▶
a character. Press [ ] and [ ] to move the cursor.
When a character is highlighted by the cursor, this
character can be changed. A character can be
inserted by placing the cursor between two
▲ ▼
characters and pressing [ ] or [
▼
] or [ ] to change a
▲ ▼
] or [ ].
◀
] and
▲
] or
▼
] or [ ] to change
].
