Parameter Description
35-25 Term. X48/7 Temp. Monitor
This parameter gives the possibility of enabling or disabling the
temperature monitor for terminal X48/7. The temperature limits
can be set in 35-26 Term. X48/7 Low Temp. Limit and 35-27 Term.
X48/7 High Temp. Limit.
Option:
[0] Disabled
[1] Enabled
35-26 Term. X48/7 Low Temp. Limit
Range:
Size related [ -50 - par. 35-27 ]
*
35-27 Term. X48/7 High Temp. Limit
Range:
Size related [ par. 35-26 - 204 ]
*
3.27.4 35-3* Temp. Input X48/10 (MCB 114)
35-34 Term. X48/10 Filter Time Constant
Range: Function:
0.001 s [0.001 - 10 Enter the filter time constant. This is a
*
s] first-order digital low pass filter time
constant for suppressing electrical noise
in terminal X48/10. A high time constant
value improves dampening but also
increases the time delay through the
filter.
35-35 Term. X48/10 Temp. Monitor
This parameter gives the possibility of enabling or disabling the
temperature monitor for terminal X48/10. The temperature limits
can be set in 35-36 Term. X48/10 Low Temp. Limit/35-37 Term.
X48/10 High Temp. Limit.
Option:
[0] Disabled
[1] Enabled
35-36 Term. X48/10 Low Temp. Limit
Range:
Size related [ -50 - par. 35-37 ]
*
35-37 Term. X48/10 High Temp. Limit
Range:
Size related [ par. 35-36 - 204 ]
*
®
VLT AQUA Drive Programming Guide
3.27.5 35-4* Analog Input X48/2 (MCB 114)
4 mA
Function:
Function:
20 mA
Function:
0
100
Function:
0.001 s
Function:
Function:
®
MG20O622 - VLT is a registered Danfoss trademark
35-42 Term. X48/2 Low Current
Range: Function:
[ 0 - par. Enter the current (mA) that corresponds to
*
35-43 mA] the low reference value, set in 35-44 Term.
X48/2 Low Ref./Feedb. Value. The value must
be set at > 2mA in order to activate the
Live Zero Timeout Function in 6-01 Live
Zero Timeout Function.
35-43 Term. X48/2 High Current
Range: Function:
[ par. 35-42 - 20 Enter the current (mA) that
*
mA] corresponds to the high reference
value (set in 35-45 Term. X48/2 High
Ref./Feedb. Value).
35-44 Term. X48/2 Low Ref./Feedb. Value
Range: Function:
[-999999.999 - Enter the reference or feedback value
*
999999.999 ] (in RPM, Hz, bar, etc.) that
corresponds to the voltage or current
set in 35-42 Term. X48/2 Low Current.
35-45 Term. X48/2 High Ref./Feedb. Value
Range: Function:
[-999999.999 - Enter the reference or feedback
*
999999.999 ] value (in RPM, Hz, bar, etc.) that
corresponds to the voltage or
current set in 35-43 Term. X48/2
High Current.
35-46 Term. X48/2 Filter Time Constant
Range: Function:
[0.001 - 10 Enter the filter time constant. This is a
*
s] first-order digital low pass filter time
constant for suppressing electrical noise
in terminal X48/2. A high time constant
value improves dampening but also
increases the time delay through the
filter.
