Parameter Description

3.10 Parameters 9-** Profibus

For Profibus parameter descriptions, see the Profibus
Instruction Manual, MG33C.
3 3

3.11 Parameters 10-** CAN Fieldbus

3.11.1 10-0* Common Settings
10-00 CAN Protocol
Option:
[1] DeviceNet
NOTICE!
The parameter options depend on installed option.
10-01 Baud Rate Select
Option:
[20] 125 Kbps
[21] 250 Kbps
[22] 500 Kbps
10-02 MAC ID
Range:
Size related
*
10-05 Readout Transmit Error Counter
Range:
0 [0 - 255 ] View the number of CAN control transmission
*
10-06 Readout Receive Error Counter
Range:
0 [0 - 255 ] View the number of CAN control receipt errors
*
10-07 Readout Bus Off Counter
Range:
0 [0 - 255 ] View the number of Bus Off events since the last
*
3-68
VLT
Function:
View the active CAN protocol.
Function:
Select the serial communication bus transmission
speed. The selection must correspond to the
transmission speed of the master and the other
serial communication bus nodes.
Function:
[ 0 - 63 ]
Function:
errors since the last power-up.
Function:
since the last power-up.
Function:
power-up.
MG20O622 - VLT
®
AQUA Drive Programming Guide
3.11.2 10-1* DeviceNet
10-10 Process Data Type Selection
Option:
[0] INSTANCE
100/150
[1] INSTANCE
101/151
[2] INSTANCE
20/70
[3] INSTANCE
21/71
®
is a registered Danfoss trademark
Function:
Select the Instance (telegram) for data
transmission. The instances available are
dependent upon the setting of 8-10 Control
Profile.
When 8-10 Control Profile is set to [0] [0] FC
profile, 10-10 Process Data Type Selection
options [0] INSTANCE 100/150 and [1]
INSTANCE 101/151 are available.
When 8-10 Control Profile is set to [5] ODVA,
10-10 Process Data Type Selection options [2]
INSTANCE 20/70 and [3] INSTANCE 21/71 are
available.
Instances 100/150 and 101/151 are Danfoss-
specific. Instances 20/70 and 21/71 are ODVA-
specific AC Drive profiles.
For guidelines in telegram selection, please
refer to the DeviceNet Instruction Manual,
MG33D.
NOTICE!
A change to this parameter will be
executed immediately.
