Parameter Description
13-51 SL Controller Event
Array [20]
Option: Function:
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Timeout 0
[31] SL Timeout 1
[32] SL Timeout 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[39] Start command
[40] Drive stopped
[41] Reset Trip
[42] Auto Reset Trip
[43] OK key
[44] Reset Key
[45] Left Key
[46] Right Key
[47] Up Key
[48] Down Key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Timeout 3
[71] SL Timeout 4
[72] SL Timeout 5
[73] SL Timeout 6
[74] SL Timeout 7
[76] Digital Input x30 2
[77] Digital Input x30 3
[78] Digital Input x30 4
[80] No Flow
[81] Dry Pump
[82] End of Curve
[83] Broken Belt
[90] ECB Drive Mode
[91] ECB Bypass Mode
[92] ECB Test Mode
®
VLT AQUA Drive Programming Guide
13-51 SL Controller Event
Array [20]
Option:
[100] Fire Mode
13-52 SL Controller Action
Array [20]
Option:
[0]
[1]
[2]
[3]
[4]
[5]
[10]
[11]
[12]
[13]
[14]
[15]
[16]
[17]
[18]
[19]
®
MG20O622 - VLT is a registered Danfoss trademark
Function:
Function:
Select the action corresponding to the
SLC event. Actions are executed when
the corresponding event (defined in
13-51 SL Controller Event) is evaluated
as true. The following actions are
available for selection:
Disabled
No action
Select set-up 1 Changes the active set-up (0-10 Active
Set-up) to '1'.
Select set-up 2 Changes the active set-up (0-10 Active
Set-up) to '2'.
Select set-up 3 Changes the active set-up (0-10 Active
Set-up) to '3'.
Select set-up 4 Changes the active set-up (0-10 Active
Set-up) to '4'. If the set-up is changed,
it will merge with other set-up
commands coming from either the
digital inputs or via a serial communi-
cation bus.
Select preset ref Selects preset reference 0.
0
Select preset ref Selects preset reference 1.
1
Select preset ref Selects preset reference 2.
2
Select preset ref Selects preset reference 3.
3
Select preset ref Selects preset reference 4.
4
Select preset ref Selects preset reference 5.
5
Select preset ref Selects preset reference 6.
6
Select preset ref Selects preset reference 7. If the active
7 preset reference is changed, it will
merge with other preset reference
commands coming from either the
digital inputs or via a serial communi-
cation bus.
Select ramp 1 Selects ramp 1
Select ramp 2 Selects ramp 2
3 3
3-83
