Danfoss VLT AQUA Drive FC 200 Programming Manual page 128

Parameter Description
16-82 Fieldbus REF 1
Range:
0 [-200 -
*
3 3
200 ]
16-84 Comm. Option Status
Range:
0 [0 - 65535 ] View the extended ser. comm. option status
*
16-85 FC Port CTW 1
Range:
0 [0 - 65535 ] View the two-byte control word (CTW)
*
16-86 FC Port REF 1
Range:
0 [-200 -
*
200 ]
3.15.6 16-9* Diagnosis Readouts
16-90 Alarm Word
Range:
0 [0 - 4294967295 ] View the alarm word sent via the serial
*
16-91 Alarm Word 2
Range:
0 [0 - 4294967295 ] View the alarm word 2 sent via the
*
16-92 Warning Word
Range:
0 [0 - 4294967295 ] View the warning word sent via the
*
3-102
VLT
Function:
View the two-byte word sent with the control
word form the bus master to set the reference
value.
For more information, refer to the relevant
serial communication bus manual.
Function:
word.
For more information, refer to the relevant
serial communication bus manual.
Function:
received from the bus master. Interpretation
of the control word depends on the serial
communication option installed and the
control word profile selected in 8-10 Control
Profile.
Function:
View the two-byte status word (STW) sent to
the bus master. Interpretation of the status
word depends on the serial communication
bus option installed and the control word
profile selected in 8-10 Control Profile.
Function:
communication port in hex code.
Function:
serial communication port in hex code.
Function:
serial communication port in hex code.
MG20O622 - VLT
®
AQUA Drive Programming Guide
16-93 Warning Word 2
Range:
0 [0 - 4294967295 ] View the warning word 2 sent via the
*
16-94 Ext. Status Word
Range:
0 [0 - 4294967295 ] Returns the extended status word sent
*
16-95 Ext. Status Word 2
Range:
0 [0 - 4294967295 ] Returns the extended warning word 2
*
16-96 Maintenance Word
Range:
0 [0 -
4294967295 ]
*
®
is a registered Danfoss trademark
Function:
serial communication port in hex code.
Function:
via the serial communication port in hex
code.
Function:
sent via the serial communication port
in hex code.
Function:
Readout of the Preventive Maintenance
Word. The bits reflect the status for the
programmed preventive maintenance events
in parameter group 23-1*. 13 bits represent
combinations of all the possible items:
•
Bit 0: Motor bearings
•
Bit 1: Pump bearings
•
Bit 2: Fan bearings
•
Bit 3: Valve
•
Bit 4: Pressure transmitter
•
Bit 5: Flow transmitter
•
Bit 6: Temperature transmitter
•
Bit 7: Pump seals
•
Bit 8: Fan belt
•
Bit 9: Filter
•
Bit 10: Drive cooling fan
•
Bit 11: Drive system health check
•
Bit 12: Warranty
•
Bit 13: Maintenance Text 0
•
Bit 14: Maintenance Text 1
•
Bit 15: Maintenance Text 2
•
Bit 16: Maintenance Text 3
•
Bit 17: Maintenance Text 4
